Główne cechu urządzenia:
Dane techniczne:
| Motherboard | D36 |
|
| Processor | Intel Celeron J1900 2.41 GHz, L2 2MB (10W) | |
| Chipset | N/A; including in CPU | |
| System Memory | 1x DDR3L-1066/1333Hz, SO-DIMM, default 2GB | |
| Graphic Memory | Intel HD Graphic DX11 and OCL1.1 | |
| LCD Touch Panel | ||
| LCD Size | 14” LED Panel | |
| Brightness | 200 nits | |
| Resolution | 1366 x 768 | |
| Touch Screen | True-Flat Resistive Touch | |
| Tilt Adjustment | 10°~90° | |
| Storage Device | ||
| Hard Drive | 1x 2.5” SATA HDD | |
| Flash Memory | 1x SATA SSD card (option) | |
| Expansion | ||
| Mini PCI-E Socket | 1 | |
| External I/O Ports | ||
| USB | 6 (5 x USB 2.0 (1 by cable type option), 1 x USB3.0) | |
| Serial Port | 3x RJ45 COM (COM1 / COM2 W/5V, COM3 W/12V powered enabled by BIOS)) | |
| GigaLAN (10/100/1000) | 1 (RJ45) | |
| VGA | 1 (12V power enable by BIOS)) | |
| Cash Drawer | 1 (RJ11, 12V/24V, default 24V by Jumper setting) | |
| DC Jack1 | 1 | |
| Audio Line-out | 1 | |
| PS/2 | 1 | |
| Power | ||
| Power Supply | External adapter, 65W/ 19V | |
| Control / Indicator | ||
| Power Button | 1 | |
| Power Switch | 1 | |
| Power LED | 1 | |
| Peripheral (Option) | ||
| MSR | 1 (USB) | |
| i-Button | 1 (USB) | |
| Fingerprint | 1 (USB) | |
| 2nd Display | 14” without touch | |
| Customer Display | LCM (USB) | |
| Certificate | ||
| EMC & Safety | FCC, CE Class A, LVD | |
| Environment | ||
| Operating Temperature | 0°C ~ 35°C ( 32°F ~ 95°F ) | |
| Storage Temperature | -20°C ~60°C (-4°F ~ 140°F) | |
| Humidity | 20% - 85% RH non condensing | |
| Communication | ||
| Wireless LAN | 802.11 b/g/n Wireless LAN card & antenna (option) | |
| Dimension (W x D x H) | LCD 60° tilt angle: 380 x 195 x 278 mm (15" x 7.6" x 10.9") | |
| Weight | 3.7 kg (8.13 lbs) | |
| Mounting | 75 x 75 mm VESA mounting hole for panel PC type | |
